60KVA CNC Bending Machine Production Line For Steel Materials

Minimum Order Quantity : 1 Set/Sets Price : negotiable
Packaging Details : 1 Outside: carton box printed mark and detailed information. 2 Inside: standard EPE foam. Corner protector, protective edging or other requests is available Delivery Time : 150 Days~200 Days
Payment Terms : T/T, L/C Supply Ability : 550 Units/Year Pieces/Year
Place of Origin: LUOYANG, HENAN, CHINA Brand Name: CBNT & ODM
Certification: ISO9001/ CE/ Others Model Number: CBNT-UN2200HBZHSCX

Detail Information

Type: CNC Bending Equipment Function: Auto Bending And Welding For Metal Materials
General Use: Manufacturing Plant/ Building Material Shops Short Edge Bending Machine: REGULAR: 1850*2220*1950mm
Long Edge Bending Machine: REGULAR: 1650*2300*1650mm Bending Speed: ≤ 0.5s
Material Scope: Q235/ Others Color: Yellow/ Red/ Blue/Customized
Capacitance: 60KVA (380V、50Hz) Warranty Of Core Components: Mainly Parts: One Year, Other Parts: Lifetime
Weight: ≈15~20 Ton Barometric Pressure: ≈0.5MPa~0.6MPa
Size Of Equipment: L14m * W4m * H3.5m Business Type: ODM
Port: QingDao Port, China Size: ≈ Length11,000mm * Wide4300mm
Product Range: L=2100mm; W=950mm (finished) Height Of Equipment: ≈900mm ± 50mm (from The Ground)
Plate Material Thickness: Cold-roll Steel Sheets 0.5-1.2mm Thickness
High Light:

60KVA CNC Bending Machine

,

CNC Bending Machine For Steel Materials

,

60KVA cnc steel bending machine

Product Description

60KVA CNC Bending Machine Production Line For Steel Materials 0

 CNC Automatic Bending Equipment Production Line



     Selecting our shelf boards automatic bending and spot welding production line, the cutting plate can be bent at both ends of the short side of the plate through the double end bending center, then through the long sides of the bending center of the plate, which can bend multiple times at the same time. Through the conveyor rack to the welding line, and completes the reinforcement action through the truss robot arm.





     1. Technical Data



No.

Equipment name

Brand

Size

Amount

Function

1

 Double ends of short edge bending machine



















CBNT,

ODM&OEM

1850*2220*1950mm

1

Double ends bending

2

Double ends of  long edge bending machine

1650*2300*1650mm

1

Double ends bending

3

Leveler/Flatting machine



1

Correction leveling/ Flatting

4

Uncoiler



1

Uncoil

5

Welding line



1

spot welding, dot welding;

6

Truss robot



1

Reinforce-bar loading

7

Truss robot



1

Unloading and Stacking

8

Hand cart         (reinforce-bar)



2

Put the reinforce-bar for using

9

Operating system



1



10

Power



80KW













2. Description of equipment:

  The last step, use the truss robot to put the reinforce-bar on the shelf to finish the welding production. Using the truss robot to unload and stack to complete the shelf. Monthly output reaches 25,000pcs.



60KVA CNC Bending Machine Production Line For Steel Materials 1










  3. UN2200hbzhscx Shelf production line configuration



Specifications

Shelf Automatic production line

Size of equipment

 L14 m * W4 m * H3.5 m

Technological process

Uncoiler→Leveling→Two ends bend→Two sides bend→Rowing welding machine→Truss robot finished and Storage

Worktable production line-height of equipment:

Apart from the ground 900 ± 50mm

Material Scope

Material is Q235, stainless steel roll, and other flexible sheet metal

Barometric Pressure

0.5-0.6Mpa

Capacitance:

About 60KVA(380V,50HZ)

Thickness:

0.5-1.2mm

Product Range

Comply with the product drawing requirements confirmed by both parties/ Required by Customer

Metal sheet color

Red and black/ blue and white/Required by customer

Machining accuracy

Processing accuracy: the ultimate deviation accuracy of the tolerance dimension on the drawing is GB1804-m.

Bending speed

0.5s

CNC system

SYNTEC

Operational software

UNZ10 (Free update)

Main accessories brand



Robot brand and model

Truss robot or Borunte robot

Vacuum generator, suction cups

SMC

Original pneumatic unit and air cylinder

AIRTAC or SMC

Ball-bearing and linear guideway

HIWIN

Axle bearing

NSK

Reduction gearbox

ZD(Zhongda)

Programmable control unit(PCU)

SYNTEC (Chinese operation)

Inverter

SYNTEC

Low voltage appliances, buttons, indicator lights, air switches

Schneider

 AC contactor

Schneider

 Sensor

Panasonnic

Intermediate relay

Schneider

Servo motor

SYNTEC

Wire and cable

Delrou



General features

--Energy-saving, lower noise, accurate positioning;

--The finger-stops can be moved with a linear guide;

--Backgauge is driven by a digital AC servo motor, moved by precision ball screw, guided by the linear guide.

--High productivity and good precision for metal sheets bending;

--Different tools work for multifarious pieces. Can make complex shapes by repetitious bending work;

--Mechanical stopper in oil cylinder, typical of high feedback precision for gliding block;

--Double hydraulic oil cylinder is applied for upper transmission, provided with mechanical limit stopper and synchronous torsion bar;

--With slowly falling function, the worker can control the machine easily;

--Conventional clamps for the punch with manual wedge adjustment;

--Realization of high precision, energy saving, environmental protection, high efficiency.







SUPPLY ABILITY AND TRADING TERMS

Terms of payment

-T/T, 10% deposit before design the drawing draft, 60% before production, 20% before loading, 10% the balance after the adjustment and installation.

 Lead-time

1. Design picture draft: about 2 weeks

2. Production line: about 3 months

3. Technical training: 3days ~1 week. The company can also provide in-door installation, equipment debugging, technical training services, to guide the plant establishment and production.

APPLICATION

 Workshop/ Storage / Company / Manufacturing shop/ Production Department/ Factory
